A vacuum truck which is mounted upon a vacuum tank is called a wet substances DOT unit. By means of a vacuum pump a negative pressure is applied to this tank. This pressure creates a pressure difference between the atmosphere and its contents. This results in a suction effect: air (gas) is discharged into the atmosphere via the vacuum pump. Due to this wet substances units are also called pressure/vacuum trucks (or DOT units).

KOKS industrial DOT units, also called industrial vacuum loaders have a long history and solid reputation in the field world wide. An industrial vacuum loader is powerful and efficient; they recover, contain, and carry liquids, dry bulk powders, solids, slurries, and thick sludge from hard to reach areas. KOKS industrial DOT units are designed from the ground up, customized to our customers requirements to tackle the most demanding dry or wet industrial cleaning applications. To ensure the best fit for the industrial cleaning applications, various models, options and off-loading solutions are available.

KOKS industrial DOT units clean up a full spectrum of materials and recover and recycle valuable raw materials, including liquids, dry bulk powders, solids, slurries, drilling mud and thick sludge. These KOKS DOT units are built to endure. They are simple to operate and easy to maintain, giving you rugged performance whenever and wherever you need it. Our vacuum trucks function even in extreme conditions. KOKS industrial DOT units are reliable and durable.

When using a wet substances DOT unit, the product, as a result of this negative pressure, is captured in the sludge tank. The product can be both liquid and/or sludge. Only the vapours (gases) and particles go in the vacuum pump or the service water thank, not the vacuumed product itself. When the tank is full, the shut-off valve/ball float on the intake of the vacuum pump comes into operation. In the event excess vapours (gases) are going to be released. Before they are released in the atmosphere, a KOKS scrubber can be connected to clean them.

Brief description of how a wet substances DOT unit works:

Vacuum transport
The pressure difference results in the movement of the product.
Volume increase
The liquid seperates from the air flow, as the material makes the transistion from the suction pipe connection (6”) to the tank (which is bigger than 6”).
Filtration
Liquids/vapours are removed from the air flow in the service water tank.
Venting
A vent pipe discharges the remaining air flow.

Wet substances DOT units with DOT 407/412, ASME and/or ATEX (ex) certification are further equipped with various safety equipment. This makes them suitable for the transportation of hazardous substances on public roads. These include, for example, tank locking, nitrogen connection, impact/roll bars, etc.

Pressure/vacuum tank (clean water tank, sludge tank and service water tank)
Pumps and drive (high-pressure pump, vacuum pump and compressor)
Various control and operating systems (hydraulic, electrical and pneumatic)
Various safety devices (clamp protection, nitrogen connection, rear cover safety, rupture disk, etc.)

As the name liquid ring vacuum pump suggests, this type of pump features a liquid ring. There is no mechanical contact between the pump's moving parts. The liquid acts as small pistons, in much the same way as a traditional piston pump. As a result, the pump also develops very little heat and it is possible to achieve a deep vacuum.

When the pump starts, the liquid ring rotates at the same speed as the rotor. The rotor is slightly offset from the centre and the liquid ring features an array of small cells. A cell in the uppermost position is completely filled with water. As the cell turns, a pocket of air is created at the rotor hub.

The liquid acts as a piston as it moves away from the rotor hub to create a suction effect. As the cell passes the bottom of the chamber, the liquid begins pressing in towards the rotor hub. This causes the air to be forced out of the cell, filling it with liquid ready for the next suction cycle.

To separate the suction and compression parts of the pump, the ends of the casing are fitted with a flow plates and pump housing. Some pump types feature connections at both ends, while others (monoblock pumps) only have one at one end of the liquid ring.

Emergency clean-up
Technical chemical cleaning
Industrial cleaning
Offshore activities
Oil separation
Onshore activities
Petro-chemical activities
Well cleaning
Sewer cleaning
Septic tank cleaning
Shutdown cleaning work
Silo cleaning
Transport work
Vacuum cleaning work
Grease pit cleaning
Water surface cleaning
Collection of waste oil
Municipal cleaning
Ship cleaning
Soil boring
Pressuring liquids
Oven cleaning

KOKS United States Corporation is part of the Dutch KOKS Group an international manufacturer and supplier of vacuum trucks (DOT 407/412) and heavy industrial cleaning equipment. Founded in 1989 and has since grown into a dynamic company that operates globally and consists of seven specialised subsidiaries in the USA, The Netherlands, the Czech Republic, Saudi Arabia and participations in rental organizations that operate in The Netherlands and the United Kingdom. As a growing, innovative, healthy and reliable company, KOKS Group has gained an excellent reputation in the (petro)chemical sector and other industries as a vacuum truck (DOT 407/412) builder.

Do you have questions about the KOKS EcoVac wet DOT unit (407/412). Just get in touch with our customer service desk. We are ready to help you, 24/7. Feel free to contact us!
