Ultrasonic systems for better and faster cleaning in the industry

Ultrasonic cleaning systems

The cleaning effect of an ultrasonic bath is caused by sound waves (not perceptible to humans) passing through the water with the cleaning liquid. ​

The vibrations cause millions of air bubbles to form, which then collapse because of the sound waves. This process is called cavitation, and it removes all the dirt particles from objects that need to be cleaned. ​

This happens without scratching or abrasion and, because the liquid gets into all the corners and holes, also in places where it is hard to reach by hand.

The cleaning fluid supports the cavitation/cleaning process. Depending on the type of contamination on the object to be cleaned, different cleaning fluids may be used.

Need thorough advice?

We can imagine that you would like to know more about our products, the fields of application and our company. Make an appointment without obligation to get to know us and our extensive range of industrial cleaning machines.



We will be more than willing to tell you why thousands of professionals worldwide trust KOKS Group and KOKS equipment.



You can contact us by calling +31 (0)72 540 66 99, by emailing info@koks.com or by filling in the contact form via the link below. On working days we are available between 07.30 and 17.00 and we are happy to be of service.

Operation of an ultrasonic unit

The heating system, in combination with ultrasound, ensures the bath is heated up to a temperature of 60-85 °C. This heating causes the dirt to release quicker, enabling the cleaning liquid to work better. To keep the heat in the bath, a hydraulically-operated lid to close the bath is installed.



The hydraulic lift system provides two things; easy loading and unloading of the objects to be cleaned, and the application of EcoMove. The lift system is built into the bath, making it possible for EcoMove to be applied and to move each object up and down during the cleaning process to ensure complete cleaning.



The skimmer ensures all floating dirt particles on the cleaning liquid are discharged to a collection container. It is then possible to use an oil separator or extraction system to remove any residual product and odours.

Benefits of ultrasonic units and ultrasonic cleaning

Ultrasonic cleaning offers many advantages over manual cleaning. Difficult to clean objects, such as carburettors, heat exchangers and filters, can be cleaned easily using ultrasonic technology because the air bubbles get everywhere without damaging the object.



In addition to achieving a better and safer result, the cleaning time using ultrasonic technology is also many times lower when compared to manual cleaning. The risk for the user, compared to, for example, high-pressure cleaning, also decreases considerably.

Main components ultrasonic units

  • Ultrasonic bars
  • Heating system
  • Hydraulic lift system
  • Skimmer

Types of ultrasonic units

The operation of an ultrasonic cleaning system is therefore based on ultrasonic sound wave technology in combination with specialised, degradable chemicals.



Ultrasonic cleaning systems that work on this principle are:

  • KOKS EcoSonic 3 > 3 metre bath
  • KOKS EcoSonic 7  > 7 metre bath
  • KOKS EcoSonic 9 > 9 metre bath

Applications for the use of ultrasonic units

  • Emergency clean-up
  • High-pressure cleaning
  • Industrial cleaning
  • Offshore activities
  • Oil separation
  • Onshore activities
  • Petro-chemical activities
  • Pits cleaning
  • Shut-down cleaning activities
  • Water surface cleaning
  • Municipal cleaning
  • Ship cleaning
  • Oven cleaning

KOKS EcoSonic 3

Ultrasonic cleaning bath - 3 meter

The system is developed to generate a faster and higher cleaning level by means of ultrasonic power, in combination with specialized chemicals (degradable). Due to the microscopic level a perfect inner and outer penetration will be created.

KOKS EcoSonic 7

Ultrasonic cleaning bath - 7 meter

The system is developed to generate a faster and higher cleaning level by means of ultrasonic power, in combination with specialized chemicals (degradable). Due to the microscopic level a perfect inner and outer penetration will be created.

KOKS EcoSonic 9

Ultrasonic cleaning bath - 9 meter

The system is developed to generate a faster and higher cleaning level by means of ultrasonic power, in combination with specialized chemicals (degradable). Due to the microscopic level a perfect inner and outer penetration will be created.
